MORTISE LOCK
M132K-LK
Lever Handle Electronic Mortise Lock
Touchable Keypad
Pin Code Access
One Time Password
Automatic Locking
Mechanical Cylinder Key
Optional: Remote door lock control via BLE communication pack
SPECS
-
Handle Type
Lever Handle
-
Unlocking Method/Iris Authentication
N/A
-
Unlocking Method/Fingerprint Authentication
N/A
-
Unlocking Method/RFID Card Authenticaiton
N/A
-
Unlocking Method/Pin Code Authentication
4~10 Digits number(Max.5ea)
-
Mechanical Cylinder Key
Included
-
Door Thickness(mm)
40~50mm(Optional: 60~100mm)
-
Backset/Space Length(mm)
70.5/44mm
-
Power
6VDC(AA Batteries) x 4ea
-
Battery Life (10 times per day)
Approx. 12 months (w/o network)
Approx. 10 months(Using RF, Network options)
-
Emergency Battery
9VDC Battery Port
-
Material
Al die-cast & ABS mold
-
Weight(KG)
1.7KGS
-
Dimension(Outer: WxHxD/mm)
81.7x239x67.1mm
-
Dimension(Outer: WxHxD/mm)
84.5x239.5x36.5mm
-
Dimension(Strike Box: WxHxD/mm)
21x106x19.5mm
-
Dimension(Mortise: Front WxFront HxD/mm)
25x110x106mm
-
Optional
BLE Commnuication pack
