把手一体型

M114F-PC

Push pull Handle Electronic Mortise Lock

Fingerprint Authentication

Touchable Keypad

Pin Code Access

RFID Card

Voice Guide

Mechanical Cylinder Key

Automatic Locking

Euro Big Mortise

Optional: Remote door lock control via BLE communication pack or via RF commnunication pack for wall-pad



产品规格

  • Handle Type

    Fingerprint Push-Pull Handle

  • Unlocking Method/Iris Authentication

    N/A

  • Unlocking Method/Fingerprint Authentication

    Fingerprint Authentication

    Max. 100 users

  • Unlocking Method/RFID Card Authenticaiton

    Available Max.50ea(Mifare)

  • Unlocking Method/Pin Code Authentication

    6~13 Digits number

  • Mechanical Cylinder Key

    Included

  • Door Thickness(mm)

    40~50mm(Optional: 60~100mm)

  • Backset/Space Length(mm)

    70.5/44mm

  • Power

    6VDC(AA Batteries) x 4ea or 8ea

  • Battery Life (10 times per day)

    Approx. 12 months (w/o RF Tag registration & w/o network option)

    Approx. 10months(RF Tag registration & network option)

  • Emergency Battery

    5VDC Micro USB Port

  • Material

    Al die-cast & ABS mold

  • Weight(KG)

    4.5KGS

  • Dimension(Outer: WxHxD/mm)

    83.9x373.3x79mm

  • Dimension(Outer: WxHxD/mm)

    84.1x374.2x80mm

  • Dimension(Strike Box: WxHxD/mm)

    24x240x19.5mm

  • Dimension(Mortise: Front WxFront HxD/mm)

    24x240x106mm

  • Optional

    BLE Commnuication pack / RF Communication pack
